Contact
Examples on contact modeling
Force TransducerThis is an example for usage of *CONTACT_AUTOMATIC_SINGLE_SURFACE and *CONTACT_FORCE_TRANSDUCER_PENALTY keywords. |
Projectile BlockA quarter of a rigid projectile impacting an energy absorbing block is modeled. The block material is defined with a strain failure criteria, at failure strain of 0.150 elements are deleted. Eroding contact is employed. |
SphereA sphere is given an initial velocity. For its impact on a plate, surface to surface contact is specified. |
